Real Browser Integration Testing with Selenium Standalone, Chrome, and ASP.NET Core 2.1

May 23, '18 Comments [4] Posted in ASP.NET | DotNetCore | Open Source
Sponsored By

I find your lack of tests disturbingBuckle up kids, this is nuts and I'm probably doing it wrong. ;) And it's 2am and I wrote this fast. I'll come back tomorrow and fix the spelling.

I want to have lots of tests to make sure my new podcast site is working well. As mentioned before, I've been updating the site to ASP.NET Core 2.1.

Here's some posts if you want to catch up:

I've been doing my testing with XUnit and I want to test in layers.

Basic Unit Testing

Simply create a Razor Page's Model in memory and call OnGet or WhateverMethod. At this point you are NOT calling Http, there is no WebServer.

public IndexModel pageModel;

public IndexPageTests()
{
var testShowDb = new TestShowDatabase();
pageModel = new IndexModel(testShowDb);
}

[Fact]
public async void MainPageTest()
{
// FAKE HTTP GET "/"
IActionResult result = await pageModel.OnGetAsync(null, null);

Assert.NotNull(result);
Assert.True(pageModel.OnHomePage); //we are on the home page, because "/"
Assert.Equal(16, pageModel.Shows.Count()); //home page has 16 shows showing
Assert.Equal(620, pageModel.LastShow.ShowNumber); //last test show is #620
}

Moving out a layer...

In-Memory Testing with both Client and Server using WebApplicationFactory

Here we are starting up the app and calling it with a client, but the "HTTP" of it all is happening in memory/in process. There are no open ports, there's no localhost:5000. We can still test HTTP semantics though.

public class TestingFunctionalTests : IClassFixture<WebApplicationFactory<Startup>>
{
public HttpClient Client { get; }
public ServerFactory<Startup> Server { get; }

public TestingFunctionalTests(ServerFactory<Startup> server)
{
Client = server.CreateClient();
Server = server;
}

[Fact]
public async Task GetHomePage()
{
// Arrange & Act
var response = await Client.GetAsync("/");

// Assert
Assert.Equal(HttpStatusCode.OK, response.StatusCode);
}
...
}

Testing with a real Browser and real HTTP using Selenium Standalone and Chrome

THIS is where it gets interesting with ASP.NET Core 2.1 as we are going to fire up both the complete web app, talking to the real back end (although it could talk to a local test DB if you want) as well as a real headless version of Chrome being managed by Selenium Standalone and talked to with the WebDriver. It sounds complex, but it's actually awesome and super useful.

First I add references to Selenium.Support and Selenium.WebDriver to my Test project:

dotnet add reference "Selenium.Support"
dotnet add reference "Selenium.WebDriver"

Make sure you have node and npm then you can get Selenium Standalone like this:

npm install -g selenium-standalone@latest
selenium-standalone install

Chrome is being controlled by automated test softwareSelenium, to be clear, puts your browser on a puppet's strings. Even Chrome knows it's being controlled! It's using the (soon to be standard, but clearly defacto standard) WebDriver protocol. Imagine if your browser had a localhost REST protocol where you could interrogate it and click stuff! I've been using Selenium for over 11 years. You can even test actual Windows apps (not in the browser) with WinAppDriver/Appium but that's for another post.

Now for this part, bare with me because my ServerFactory class I'm about to make is doing two things. It's setting up my ASP.NET Core 2. 1 app and actually running it so it's listening on https://localhost:5001. It's assuming a few things that I'll point out. It also (perhaps questionable) is launching Selenium Standalone from within its constructor. Questionable, to be clear, and there's others ways to do this, but this is VERY simple.

If it offends you, remembering that you do need to start Selenium Standalone with "selenium-standalone start" you could do it OUTSIDE your test in a script.

Perhaps do the startup/teardown work in a PowerShell or Shell script. Start it up, save the process id, then stop it when you're done. Note I'm also doing checking code coverage here with Coverlet but that's not related to Selenium - I could just "dotnet test."

#!/usr/local/bin/powershell
$SeleniumProcess = Start-Process "selenium-standalone" -ArgumentList "start" -PassThru
dotnet test /p:CollectCoverage=true /p:CoverletOutputFormat=lcov /p:CoverletOutput=./lcov .\hanselminutes.core.tests
Stop-Process -Id $SeleniumProcess.Id

Here my SeleniumServerFactory is getting my Browser and Server ready.

SIDEBAR NOTE: I want to point out that this is NOT perfect and it's literally the simplest thing possible to get things working. It's my belief, though, that there are some problems here and that I shouldn't have to fake out the "new TestServer" in CreateServer there. While the new WebApplicationFactory is great for in-memory unit testing, it should be just as easy to fire up your app and use a real port for things like Selenium testing. Here I'm building and starting the IWebHostBuilder myself (!) and then making a fake TestServer only to satisfy the CreateServer method, which I think should not have a concrete class return type. For testing, ideally I could easily get either an "InMemoryWebApplicationFactory" and a "PortUsingWebApplicationFactory" (naming is hard). Hopefully this is somewhat clear and something that can be easily adjusted for ASP.NET Core 2.1.x.

My app is configured to listen on both http://localhost:5000 and https://localhost:5001, so you'll note where I'm getting that last value (in an attempt to avoid hard-coding it). We also are sure to stop both Server and Brower in Dispose() at the bottom.

public class SeleniumServerFactory<TStartup> : WebApplicationFactory<Startup> where TStartup : class
{
public string RootUri { get; set; } //Save this use by tests

Process _process;
IWebHost _host;

public SeleniumServerFactory()
{
ClientOptions.BaseAddress = new Uri("https://localhost"); //will follow redirects by default

_process = new Process() {
StartInfo = new ProcessStartInfo {
FileName = "selenium-standalone",
Arguments = "start",
UseShellExecute = true
}
};
_process.Start();
}

protected override TestServer CreateServer(IWebHostBuilder builder)
{
//Real TCP port
_host = builder.Build();
_host.Start();
RootUri = _host.ServerFeatures.Get<IServerAddressesFeature>().Addresses.LastOrDefault(); //Last is https://localhost:5001!

//Fake Server we won't use...this is lame. Should be cleaner, or a utility class
return new TestServer(new WebHostBuilder().UseStartup<TStartup>());
}

protected override void Dispose(bool disposing)
{
        base.Dispose(disposing);
        if (disposing) {
            _host.Dispose();
_process.CloseMainWindow(); //Be sure to stop Selenium Standalone
        }
    }
}

But what does a complete series of tests look like? I have a Server, a Browser, and an (theoretically optional) HttpClient. Focus on the Browser and Server.

At the point when a single test starts, my site is up (the Server) and an invisible headless Chrome (the Browser) is actually being puppeted with local calls via WebDriver. All this is hidden from to you - if you want. You can certainly see Chrome (or other browsers) get automated, but what's nice about Selenium Standalone with hidden/headless Browser testing is that my unit tests now also include these complete Integration Tests and can run as part of my Continuous Integration Build.

Again, layers. I test classes, then move out and test Http Request/Response interactions, and finally the site is up and I'm making sure I can navigate, that data is loading. I'm automating the "smoke tests" that I used to do myself! And I can make as many of this a I'd like now that the scaffolding work is done.

public class SeleniumTests : IClassFixture<SeleniumServerFactory<Startup>>, IDisposable
{
public SeleniumServerFactory<Startup> Server { get; }
public IWebDriver Browser { get; }
public HttpClient Client { get; }
public ILogs Logs { get; }

public SeleniumTests(SeleniumServerFactory<Startup> server)
{
Server = server;
Client = server.CreateClient(); //weird side effecty thing here. This call shouldn't be required for setup, but it is.

var opts = new ChromeOptions();
opts.AddArgument("--headless"); //Optional, comment this out if you want to SEE the browser window
opts.SetLoggingPreference(OpenQA.Selenium.LogType.Browser, LogLevel.All);

var driver = new RemoteWebDriver(opts);
Browser = driver;
Logs = new RemoteLogs(driver); //TODO: Still not bringing the logs over yet
}

[Fact]
public void LoadTheMainPageAndCheckTitle()
{
Browser.Navigate().GoToUrl(Server.RootUri);
Assert.StartsWith("Hanselminutes Technology Podcast - Fresh Air and Fresh Perspectives for Developers", Browser.Title);
}

[Fact]
public void ThereIsAnH1()
{
Browser.Navigate().GoToUrl(Server.RootUri);

var headerSelector = By.TagName("h1");
Assert.Equal("HANSELMINUTES PODCAST\r\nby Scott Hanselman", Browser.FindElement(headerSelector).Text);
}

[Fact]
public void KevinScottTestThenGoHome()
{
Browser.Navigate().GoToUrl(Server.RootUri + "/631/how-do-you-become-a-cto-with-microsofts-cto-kevin-scott");

var headerSelector = By.TagName("h1");
var link = Browser.FindElement(headerSelector);
link.Click();
Assert.Equal(Browser.Url.TrimEnd('/'),Server.RootUri); //WTF
}

public void Dispose()
{
Browser.Dispose();
}
}

Here's a build, unit test/selenium test with code coverage actually running. I started running it from PowerShell. The black window in the back is Selenium Standalone doing its thing (again, could be hidden).

Two consoles, one with PowerShell running XUnit and one running Selenium

If I comment out the "--headless" line, I'll see this as Chrome is automated. Cool.

Chrome is loading my site and being automated

Of course, I can also run these in the .NET Core Test Explorer in either Visual Studio Code, or Visual Studio.


Great fun. What are your thoughts?


Sponsor: Check out JetBrains Rider: a cross-platform .NET IDE. Edit, refactor, test and debug ASP.NET, .NET Framework, .NET Core, Xamarin or Unity applications. Learn more and download a 30-day trial!

About Scott

Scott Hanselman is a former professor, former Chief Architect in finance, now speaker, consultant, father, diabetic, and Microsoft employee. He is a failed stand-up comic, a cornrower, and a book author.

facebook twitter subscribe
About   Newsletter
Sponsored By
Hosting By
Dedicated Windows Server Hosting by SherWeb

Installing PowerShell Core on a Raspberry Pi (powered by .NET Core)

May 18, '18 Comments [1] Posted in Linux | Open Source | PowerShell
Sponsored By

PowerShell Core on a Raspberry Pi!Earlier this week I set up .NET Core and Docker on a Raspberry Pi and found that I could run my podcast website quite easily on a Pi. Check that post out as there's a lot going on. I can test within a Linux Container and output the test results to the host and then open them in VS. I also explored a reasonably complex Dockerfile that is both multiarch and multistage. I can reliably build and test my website either inside a container or on the bare metal of Windows or Linux. Very fun.

As primarily a Windows developer I have lots of batch/cmd files like "test.bat" or "dockerbuild.bat." They start as little throwaway bits of automation but as the project grows inevitably more complex.

I'm not interested in "selling" anyone PowerShell. If you like bash, use bash, it's lovely, as are shell scripts. PowerShell is object-oriented in its pipeline, moving lists of real objects as standard output. They are different and most importantly, they can live together. Just like you might call Python scripts from bash, you can call PowerShell scripts from bash, or vice versa. Another tool in our toolkits.

PS /home/pi> Get-Process | Where-Object WorkingSet -gt 10MB

NPM(K) PM(M) WS(M) CPU(s) Id SI ProcessName
------ ----- ----- ------ -- -- -----------
0 0.00 10.92 890.87 917 917 docker-containe
0 0.00 35.64 1,140.29 449 449 dockerd
0 0.00 10.36 0.88 1272 037 light-locker
0 0.00 20.46 608.04 1245 037 lxpanel
0 0.00 69.06 32.30 3777 749 pwsh
0 0.00 31.60 107.74 647 647 Xorg
0 0.00 10.60 0.77 1279 037 zenity
0 0.00 10.52 0.77 1280 037 zenity

Bash and shell scripts are SUPER powerful. It's a whole world. But it is text based (or json for some newer things) so you're often thinking about text more.

pi@raspberrypidotnet:~ $ ps aux | sort -rn -k 5,6 | head -n6
root 449 0.5 3.8 956240 36500 ? Ssl May17 19:00 /usr/bin/dockerd -H fd://
root 917 0.4 1.1 910492 11180 ? Ssl May17 14:51 docker-containerd --config /var/run/docker/containerd/containerd.toml
root 647 0.0 3.4 155608 32360 tty7 Ssl+ May17 1:47 /usr/lib/xorg/Xorg :0 -seat seat0 -auth /var/run/lightdm/root/:0 -nolisten tcp vt7 -novtswitch
pi 1245 0.2 2.2 153132 20952 ? Sl May17 10:08 lxpanel --profile LXDE-pi
pi 1272 0.0 1.1 145928 10612 ? Sl May17 0:00 light-locker
pi 1279 0.0 1.1 145020 10856 ? Sl May17 0:00 zenity --warning --no-wrap --text

You can take it as far as you like. For some it's intuitive power, for others, it's baroque.

pi@raspberrypidotnet:~ $ ps -eo size,pid,user,command --sort -size | awk '{ hr=$1/1024 ; printf("%13.2f Mb ",hr) } { for ( x=4 ; x<=NF ; x++ ) { printf("%s ",$x) } print "" }'
0.00 Mb COMMAND
161.14 Mb /usr/bin/dockerd -H fd://
124.20 Mb docker-containerd --config /var/run/docker/containerd/containerd.toml
78.23 Mb lxpanel --profile LXDE-pi
66.31 Mb /usr/lib/xorg/Xorg :0 -seat seat0 -auth /var/run/lightdm/root/:0 -nolisten tcp vt7 -novtswitch
61.66 Mb light-locker

Point is, there's choice. Here's a nice article about PowerShell from the perspective of a Linux user. Can I install PowerShell on my Raspberry Pi (or any Linux machine) and use the same scripts in both places? YES.

For many years PowerShell was a Windows-only thing that was part of the closed Windows ecosystem. In fact, here's video of me nearly 12 years ago (I was working in banking) talking to Jeffrey Snover about PowerShell. Today, PowerShell is open source up at https://github.com/PowerShell with lots of docs and scripts, also open source. PowerShell is supported on Windows, Mac, and a half-dozen Linuxes. Sound familiar? That's because it's powered (ahem) by open source cross platform .NET Core. You can get PowerShell Core 6.0 here on any platform.

Don't want to install it? Start it up in Docker in seconds with

docker run -it microsoft/powershell

Sweet. How about Raspbian on my ARMv7 based Raspberry Pi? I was running Raspbian Jessie and PowerShell is supported on Raspbian Stretch (newer) so I upgraded from Jesse to Stretch (and tidied up and did the firmware while I'm at it) with:

$ sudo apt-get update
$ sudo apt-get upgrade
$ sudo apt-get dist-upgrade
$ sudo sed -i 's/jessie/stretch/g' /etc/apt/sources.list
$ sudo sed -i 's/jessie/stretch/g' /etc/apt/sources.list.d/raspi.list
$ sudo apt-get update && sudo apt-get upgrade -y
$ sudo apt-get dist-upgrade -y
$ sudo rpi-update

Cool. Now I'm on Raspbian Stretch on my Raspberry Pi 3. Let's install PowerShell! These are just the most basic Getting Started instructions. Check out GitHub for advanced and detailed info if you have issues with prerequisites or paths.

NOTE: Here I'm getting PowerShell Core 6.0.2. Be sure to check the releases page for newer releases if you're reading this in the future. I've also used 6.1.0 (in preview) with success. The next 6.1 preview will upgrade to .NET Core 2.1. If you're just evaluating, get the latest preview as it'll have the most recent bug fixes.

$ sudo apt-get install libunwind8
$ wget https://github.com/PowerShell/PowerShell/releases/download/v6.0.2/powershell-6.0.2-linux-arm32.tar.gz
$ mkdir ~/powershell
$ tar -xvf ./powershell-6.0.2-linux-arm32.tar.gz -C ~/powershell
$ sudo ln -s ~/powershell/pwsh /usr/bin/pwsh
$ sudo ln -s ~/powershell/pwsh /usr/local/bin/powershell
$ powershell

Lovely.

GOTCHA: Because I upgraded from Jessie to Stretch, I ran into a bug where libssl1.0.0 is getting loaded over libssl1.0.2. This is a complex native issue with interaction between PowerShell and .NET Core 2.0 that's being fixed. Only upgraded machines like mind will it it, but it's easily fixed with sudo apt-get remove libssl1.0.0

Now this means my PowerShell build scripts can work on both Windows and Linux. This is a deeply trivial example (just one line) but note the "shebang" at the top that lets Linux know what a *.ps1 file is for. That means I can keep using bash/zsh/fish on Raspbian, but still "build.ps1" or "test.ps1" on any platform.

#!/usr/local/bin/powershell
dotnet watch --project .\hanselminutes.core.tests test /p:CollectCoverage=true /p:CoverletOutputFormat=lcov /p:CoverletOutput=./lcov

Here's a few totally random but lovely PowerShell examples:

PS /home/pi> Get-Date | Select-Object -Property * | ConvertTo-Json
{
"DisplayHint": 2,
"DateTime": "Sunday, May 20, 2018 5:55:35 AM",
"Date": "2018-05-20T00:00:00+00:00",
"Day": 20,
"DayOfWeek": 0,
"DayOfYear": 140,
"Hour": 5,
"Kind": 2,
"Millisecond": 502,
"Minute": 55,
"Month": 5,
"Second": 35,
"Ticks": 636623925355021162,
"TimeOfDay": {
"Ticks": 213355021162,
"Days": 0,
"Hours": 5,
"Milliseconds": 502,
"Minutes": 55,
"Seconds": 35,
"TotalDays": 0.24693868190046295,
"TotalHours": 5.9265283656111105,
"TotalMilliseconds": 21335502.1162,
"TotalMinutes": 355.59170193666665,
"TotalSeconds": 21335.502116199998
},
"Year": 2018
}

You can take PowerShell objects to and from Objects, Hashtables, JSON, etc.

PS /home/pi> $hash | ConvertTo-Json
{
"Shape": "Square",
"Color": "Blue",
"Number": 1
}
PS /home/pi> $hash = @{ Number = 1; Shape = "Square"; Color = "Blue"}
PS /home/pi> $hash

Name Value
---- -----
Shape Square
Color Blue
Number 1


PS /home/pi> $hash | ConvertTo-Json
{
"Shape": "Square",
"Color": "Blue",
"Number": 1
}

Here's a nice one from MCPMag:

PS /home/pi> $URI = "https://query.yahooapis.com/v1/public/yql?q=select  * from weather.forecast where woeid in (select woeid from geo.places(1) where  text='{0}, {1}')&format=json&env=store://datatables.org/alltableswithkeys"  -f 'Omaha','NE'
PS /home/pi> $Data = Invoke-RestMethod -Uri $URI
PS /home/pi> $Data.query.results.channel.item.forecast|Format-Table

code date day high low text
---- ---- --- ---- --- ----
39 20 May 2018 Sun 62 56 Scattered Showers
30 21 May 2018 Mon 78 53 Partly Cloudy
30 22 May 2018 Tue 88 61 Partly Cloudy
4 23 May 2018 Wed 89 67 Thunderstorms
4 24 May 2018 Thu 91 68 Thunderstorms
4 25 May 2018 Fri 92 69 Thunderstorms
34 26 May 2018 Sat 89 68 Mostly Sunny
34 27 May 2018 Sun 85 65 Mostly Sunny
30 28 May 2018 Mon 85 63 Partly Cloudy
47 29 May 2018 Tue 82 63 Scattered Thunderstorms

Or a one-liner if you want to be obnoxious.

PS /home/pi> (Invoke-RestMethod -Uri  "https://query.yahooapis.com/v1/public/yql?q=select  * from weather.forecast where woeid in (select woeid from geo.places(1) where  text='Omaha, NE')&format=json&env=store://datatables.org/alltableswithkeys").query.results.channel.item.forecast|Format-Table

Example: This won't work on Linux as it's using Windows specific AIPs, but if you've got PowerShell on your Windows machine, try out this one-liner for a cool demo:

iex (New-Object Net.WebClient).DownloadString("http://bit.ly/e0Mw9w")

Thoughts?


Sponsor: Check out JetBrains Rider: a cross-platform .NET IDE. Edit, refactor, test and debug ASP.NET, .NET Framework, .NET Core, Xamarin or Unity applications. Learn more and download a 30-day trial!

About Scott

Scott Hanselman is a former professor, former Chief Architect in finance, now speaker, consultant, father, diabetic, and Microsoft employee. He is a failed stand-up comic, a cornrower, and a book author.

facebook twitter subscribe
About   Newsletter
Sponsored By
Hosting By
Dedicated Windows Server Hosting by SherWeb

Building, Running, and Testing .NET Core and ASP.NET Core 2.1 in Docker on a Raspberry Pi (ARM32)

May 16, '18 Comments [13] Posted in Docker | DotNetCore
Sponsored By

I love me some Raspberry Pi. They are great little learning machines and are super fun for kids to play with. Even if those kids are adults and they build a 6 node Kubernetes Raspberry Pi Cluster.

Open source .NET Core runs basically everywhere - Windows, Mac, and a dozen Linuxes. However, there is an SDK (that compiles and builds) and a Runtime (that does the actual running of your app). In the past, the .NET Core SDK (to be clear, the ability to "dotnet build") wasn't supported on ARMv7/ARMv8 chips like the Raspberry Pi. Now it is.

.NET Core is now supported on Linux ARM32 distros, like Raspbian and Ubuntu!

Note: .NET Core 2.1 is supported on Raspberry Pi 2+. It isn’t supported on the Pi Zero or other devices that use an ARMv6 chip. .NET Core requires ARMv7 or ARMv8 chips, like the ARM Cortex-A53. Folks on the Azure IoT Edge team use the .NET Core Bionic ARM32 Docker images to support developers writing C# with Edge devices.

There's two ways to run .NET Core on a Raspberry Pi.

One, use Docker. This is literally the fastest and easiest way to get .NET Core up and running on a Pi. It sounds crazy but Raspberry Pis are brilliant little Docker container capable systems. You can do it in minutes, truly. You can install Docker quickly on a Raspberry Pi with just:

curl -sSL https://get.docker.com | sh
sudo usermod -aG docker pi

After installing Docker you'll want to log in and out. You might want to try a quick sample to make sure .NET Core runs! You can explore the available Docker tags at https://hub.docker.com/r/microsoft/dotnet/tags/ and you can read about the .NET Core Docker samples here https://github.com/dotnet/dotnet-docker/tree/master/samples/dotnetapp

Now I can just docker run and then pass in "dotnet --info" to find out about dotnet on my Pi.

pi@raspberrypi:~ $ docker run --rm -it microsoft/dotnet:2.1-sdk dotnet --info
.NET Core SDK (reflecting any global.json):
Version: 2.1.300-rc1-008673
Commit: f5e3ddbe73

Runtime Environment:
OS Name: debian
OS Version: 9
OS Platform: Linux
RID: debian.9-x86
Base Path: /usr/share/dotnet/sdk/2.1.300-rc1-008673/

Host (useful for support):
Version: 2.1.0-rc1
Commit: eb9bc92051

.NET Core SDKs installed:
2.1.300-rc1-008673 [/usr/share/dotnet/sdk]

.NET Core runtimes installed:
Microsoft.NETCore.App 2.1.0-rc1 [/usr/share/dotnet/shared/Microsoft.NETCore.App]

To install additional .NET Core runtimes or SDKs:
https://aka.ms/dotnet-download

This is super cool. There I'm on the Raspberry Pi (RPi) and I just ask for the dotnet:2.1-sdk and because they are using "multiarch" docker files, Docker does the right thing and it just works. If you want to use .NET Core on ARM32 with Docker, you can use any of the following tags.

Note: The first three tags are multi-arch and bionic is Ubuntu 18.04. The codename stretch is Debian 9. So I'm using 2.1-sdk and it's working on my RPi, but I can be specific if I'd prefer.

  • 2.1-sdk
  • 2.1-runtime
  • 2.1-aspnetcore-runtime
  • 2.1-sdk-stretch-arm32v7
  • 2.1-runtime-stretch-slim-arm32v7
  • 2.1-aspnetcore-runtime-stretch-slim-arm32v7
  • 2.1-sdk-bionic-arm32v7
  • 2.1-runtime-bionic-arm32v7
  • 2.1-aspnetcore-runtime-bionic-arm32v7

Try one in minutes like this:

docker run --rm microsoft/dotnet-samples:dotnetapp

Here it is downloading the images...

Docker on a Raspberry Pi

In previous versions of .NET Core's Dockerfiles it would fail if you were running an x64 image on ARM:

standard_init_linux.go:190: exec user process caused "exec format error"

Different processors! But with multiarch per https://github.com/dotnet/announcements/issues/14 Kendra from Microsoft it just works with 2.1.

Docker has a multi-arch feature that microsoft/dotnet-nightly recently started utilizing. The plan is to port this to the official microsoft/dotnet repo shortly. The multi-arch feature allows a single tag to be used across multiple machine configurations. Without this feature each architecture/OS/platform requires a unique tag. For example, the microsoft/dotnet:1.0-runtime tag is based on Debian and microsoft/dotnet:1.0-runtime-nanoserver if based on Nano Server. With multi-arch there will be one common microsoft/dotnet:1.0-runtime tag. If you pull that tag from a Linux container environment you will get the Debian based image whereas if you pull that tag from a Windows container environment you will get the Nano Server based image. This helps provide tag uniformity across Docker environments thus eliminating confusion.

In these examples above I can:

  • Run a preconfigured app within a Docker image like:
    • docker run --rm microsoft/dotnet-samples:dotnetapp
  • Run dotnet commands within the SDK image like:
    • docker run --rm -it microsoft/dotnet:2.1-sdk dotnet --info
  • Run an interactive terminal within the SDK image like:
    • docker run --rm -it microsoft/dotnet:2.1-sdk

As a quick example, here I'll jump into a container and new up a quick console app and run it, just to prove I can. This work will be thrown away when I exit the container.

pi@raspberrypi:~ $ docker run --rm -it microsoft/dotnet:2.1-sdk
root@063f3c50c88a:/# ls
bin boot dev etc home lib media mnt opt proc root run sbin srv sys tmp usr var
root@063f3c50c88a:/# cd ~
root@063f3c50c88a:~# mkdir mytest
root@063f3c50c88a:~# cd mytest/
root@063f3c50c88a:~/mytest# dotnet new console
The template "Console Application" was created successfully.

Processing post-creation actions...
Running 'dotnet restore' on /root/mytest/mytest.csproj...
Restoring packages for /root/mytest/mytest.csproj...
Installing Microsoft.NETCore.DotNetAppHost 2.1.0-rc1.
Installing Microsoft.NETCore.DotNetHostResolver 2.1.0-rc1.
Installing NETStandard.Library 2.0.3.
Installing Microsoft.NETCore.DotNetHostPolicy 2.1.0-rc1.
Installing Microsoft.NETCore.App 2.1.0-rc1.
Installing Microsoft.NETCore.Platforms 2.1.0-rc1.
Installing Microsoft.NETCore.Targets 2.1.0-rc1.
Generating MSBuild file /root/mytest/obj/mytest.csproj.nuget.g.props.
Generating MSBuild file /root/mytest/obj/mytest.csproj.nuget.g.targets.
Restore completed in 15.8 sec for /root/mytest/mytest.csproj.

Restore succeeded.
root@063f3c50c88a:~/mytest# dotnet run
Hello World!
root@063f3c50c88a:~/mytest# dotnet exec bin/Debug/netcoreapp2.1/mytest.dll
Hello World!

If you try it yourself, you'll note that "dotnet run" isn't very fast. That's because it does a restore, build, and run. Compilation isn't super quick on these tiny devices. You'll want to do as little work as possible. Rather than a "dotnet run" all the time, I'll do a "dotnet build" then a "dotnet exec" which is very fast.

If you're doing to do Docker and .NET Core, I can't stress enough how useful the resources are over at https://github.com/dotnet/dotnet-docker.

Building .NET Core Apps with Docker

Develop .NET Core Apps in a Container

  • Develop .NET Core Applications - This sample shows how to develop, build and test .NET Core applications with Docker without the need to install the .NET Core SDK.
  • Develop ASP.NET Core Applications - This sample shows how to develop and test ASP.NET Core applications with Docker without the need to install the .NET Core SDK.

Optimizing Container Size

ARM32 / Raspberry Pi

I found the samples to be super useful...be sure to dig into the Dockerfiles themselves as it'll give you a ton of insight into how to structure your own files. Being able to do Multistage Dockerfiles is crucial when building on a small device like a RPi. You want to do as little work as possible and let Docker cache as many layers with its internal "smarts." If you're not thoughtful about this, you'll end up wasting 10x the time building image layers every build.

Dockerizing a real ASP.NET Core Site with tests!

Can I take my podcast site and Dockerize it and build/test/run it on a Raspberry Pi? YES.

FROM microsoft/dotnet:2.1-sdk AS build
WORKDIR /app

# copy csproj and restore as distinct layers
COPY *.sln .
COPY hanselminutes.core/*.csproj ./hanselminutes.core/
COPY hanselminutes.core.tests/*.csproj ./hanselminutes.core.tests/
RUN dotnet restore

# copy everything else and build app
COPY . .
WORKDIR /app/hanselminutes.core
RUN dotnet build


FROM build AS testrunner
WORKDIR /app/hanselminutes.core.tests
ENTRYPOINT ["dotnet", "test", "--logger:trx"]


FROM build AS test
WORKDIR /app/hanselminutes.core.tests
RUN dotnet test


FROM build AS publish
WORKDIR /app/hanselminutes.core
RUN dotnet publish -c Release -o out


FROM microsoft/dotnet:2.1-aspnetcore-runtime AS runtime
WORKDIR /app
COPY --from=publish /app/hanselminutes.core/out ./
ENTRYPOINT ["dotnet", "hanselminutes.core.dll"]

Love it. Now I can "docker build ." on my Raspberry Pi. It will restore, test, and build. If the tests fail, the Docker build will fail.

See how there's an extra section up there called "testrunner" and then after it is "test?" That testrunner section is a no-op. It sets an ENTRYPOINT but it is never used...yet. The ENTRYPOINT is an implicit run if it is the last line in the Dockerfile. That's there so I can "Run up to it" if I want to.

I can just build and run like this:

docker build -t podcast .
docker run --rm -it -p 8000:80 podcast

NOTE/GOTCHA: Note that the "runtime" image is microsoft/dotnet:2.1-aspnetcore-runtime, not microsoft/dotnet:2.1-runtime. That aspnetcore one pre-includes the binaries I need for running an ASP.NET app, that way I can just include a single reference to "<PackageReference Include="Microsoft.AspNetCore.App" Version="2.1.0-rc1-final" />" in my csproj. If didn't use the aspnetcore-runtime base image, I'd need to manually pull in all the ASP.NET Core packages that I want. Using the base image might make the resulting image files larger, but it's a balance between convenience and size. It's up to you. You can manually include just the packages you need, or pull in the "Microsoft.AspNetCore.App" meta-package for convenience. My resulting "podcast" image ended up 205megs, so not to bad, but of course if I wanted I could trim in a number of ways.

Or, if I JUST want test results from Docker, I can do this! That means I can run the tests in the Docker container, mount a volume between the Linux container and (theoretical) Window host, and then open the .trx resulting file in Visual Studio!

docker build --pull --target testrunner -t podcast:test .
docker run --rm -v D:\github\hanselminutes-core\TestResults:/app/hanselminutes.core.tests/TestResults podcast:test

Check it out! These are the test results from the tests that ran within the Linux Container:

XUnit Tests from within a Docker Container on Linux viewed within Visual Studio on Windows

Here's the result. I've now got my Podcast website running in Docker on an ARM32 Raspberry Pi 3 with just an hours' work (writing the Dockerfile)!

It's my podcast site running under Docker on .NET Core 2.1 on a Raspberry Pi

Second - did you make it this far down? - You can just install the .NET Core 2.1 SDK "on the metal." No Docker, just get the tar.gz and set it up. Looking at the RPi ARM32v7 Dockerfile, I can install it on the metal like this. Note I'm getting the .NET Core SDK *and* the ASP.NET Core shared runtime. In the final release build you will just get the SDK and it'll include everything, including ASP.NET.

$ sudo apt-get -y update
$ sudo apt-get -y install libunwind8 gettext
$ wget https://dotnetcli.blob.core.windows.net/dotnet/Sdk/2.1.300-rc1-008673/dotnet-sdk-2.1.300-rc1-008673-linux-arm.tar.gz
$ wget https://dotnetcli.blob.core.windows.net/dotnet/aspnetcore/Runtime/2.1.0-rc1-final/aspnetcore-runtime-2.1.0-rc1-final-linux-arm.tar.gz
$ sudo mkdir /opt/dotnet
$ sudo tar -xvf dotnet-sdk-2.1.300-rc1-008673-linux-arm.tar.gz -C /opt/dotnet/
$ sudo tar -xvf aspnetcore-runtime-2.1.0-rc1-final-linux-arm.tar.gz -C /opt/dotnet/
$ sudo ln -s /opt/dotnet/dotnet /usr/local/bin
$ dotnet --info

Cross-platform for the win!


Sponsor: Check out JetBrains Rider: a cross-platform .NET IDE. Edit, refactor, test and debug ASP.NET, .NET Framework, .NET Core, Xamarin or Unity applications. Learn more and download a 30-day trial!

About Scott

Scott Hanselman is a former professor, former Chief Architect in finance, now speaker, consultant, father, diabetic, and Microsoft employee. He is a failed stand-up comic, a cornrower, and a book author.

facebook twitter subscribe
About   Newsletter
Sponsored By
Hosting By
Dedicated Windows Server Hosting by SherWeb

Using LazyCache for clean and simple .NET Core in-memory caching

May 12, '18 Comments [18] Posted in ASP.NET | DotNetCore | Open Source
Sponsored By

Tai Chi by Luisen Rodrigo - Used under CCI'm continuing to use .NET Core 2.1 to power my Podcast Site, and I've done a series of posts on some of the experiments I've been doing. I also upgraded to .NET Core 2.1 RC that came out this week. Here's some posts if you want to catch up:

Having a blast, if I may say so.

I've been trying a number of ways to cache locally. I have an expensive call to a backend (7-8 seconds or more, without deserialization) so I want to cache it locally for a few hours until it expires. I have a way that work very well using a SemaphoreSlim. There's some issues to be aware of but it has been rock solid. However, in the comments of the last caching post a number of people suggested I use "LazyCache."

Alastair from the LazyCache team said this in the comments:

LazyCache wraps your "build stuff I want to cache" func in a Lazy<> or an AsyncLazy<> before passing it into MemoryCache to ensure the delegate only gets executed once as you retrieve it from the cache. It also allows you to swap between sync and async for the same cached thing. It is just a very thin wrapper around MemoryCache to save you the hassle of doing the locking yourself. A netstandard 2 version is in pre-release.
Since you asked the implementation is in CachingService.cs#L119 and proof it works is in CachingServiceTests.cs#L343

Nice! Sounds like it's worth trying out. Most importantly, it'll allow me to "refactor via subtraction."

I want to have my "GetShows()" method go off and call the backend "database" which is a REST API over HTTP living at SimpleCast.com. That backend call is expensive and doesn't change often. I publish new shows every Thursday, so ideally SimpleCast would have a standard WebHook and I'd cache the result forever until they called me back. For now I will just cache it for 8 hours - a long but mostly arbitrary number. Really want that WebHook as that's the correct model, IMHO.

LazyCache was added on my Configure in Startup.cs:

services.AddLazyCache();

Kind of anticlimactic. ;)

Then I just make a method that knows how to populate my cache. That's just a "Func" that returns a Task of List of Shows as you can see below. Then I call IAppCache's "GetOrAddAsync" from LazyCache that either GETS the List of Shows out of the Cache OR it calls my Func, does the actual work, then returns the results. The results are cached for 8 hours. Compare this to my previous code and it's a lot cleaner.

public class ShowDatabase : IShowDatabase
{
    private readonly IAppCache _cache;
    private readonly ILogger _logger;
    private SimpleCastClient _client;

    public ShowDatabase(IAppCache appCache,
            ILogger<ShowDatabase> logger,
            SimpleCastClient client)
    {
        _client = client;
        _logger = logger;
        _cache = appCache;
    }

    public async Task<List<Show>> GetShows()
    {
        Func<Task<List<Show>>> showObjectFactory = () => PopulateShowsCache();
        var retVal = await _cache.GetOrAddAsync("shows", showObjectFactory, DateTimeOffset.Now.AddHours(8));
        return retVal;
    }

    private async Task<List<Show>> PopulateShowsCache()
    {
        List<Show> shows = await _client.GetShows();
        _logger.LogInformation($"Loaded {shows.Count} shows");
        return shows.Where(c => c.PublishedAt < DateTime.UtcNow).ToList();
    }
}

It's always important to point out there's a dozen or more ways to do this. I'm not selling a prescription here or The One True Way, but rather exploring the options and edges and examining the trade-offs.

  • As mentioned before, me using "shows" as a magic string for the key here makes no guarantees that another co-worker isn't also using "shows" as the key.
    • Solution? Depends. I could have a function-specific unique key but that only ensures this function is fast twice. If someone else is calling the backend themselves I'm losing the benefits of a centralized (albeit process-local - not distributed like Redis) cache.
  • I'm also caching the full list and then doing a where/filter every time.
    • A little sloppiness on my part, but also because I'm still feeling this area out. Do I want to cache the whole thing and then let the callers filter? Or do I want to have GetShows() and GetActiveShows()? Dunno yet. But worth pointing out.
  • There's layers to caching. Do I cache the HttpResponse but not the deserialization? Here I'm caching the List<Shows>, complete. I like caching List<T> because a caller can query it, although I'm sending back just active shows (see above).
    • Another perspective is to use the <cache> TagHelper in Razor and cache Razor's resulting rendered HTML. There is value in caching the object graph, but I need to think about perhaps caching both List<T> AND the rendered HTML.
    • I'll explore this next.

I'm enjoying myself though. ;)

Go explore LazyCache! I'm using beta2 but there's a whole number of releases going back years and it's quite stable so far.

Lazy cache is a simple in-memory caching service. It has a developer friendly generics based API, and provides a thread safe cache implementation that guarantees to only execute your cachable delegates once (it's lazy!). Under the hood it leverages ObjectCache and Lazy to provide performance and reliability in heavy load scenarios.

For ASP.NET Core it's quick to experiment with LazyCache and get it set up. Give it a try, and share your favorite caching techniques in the comments.

Tai Chi photo by Luisen Rodrigo used under Creative Commons Attribution 2.0 Generic (CC BY 2.0), thanks!


Sponsor: Check out JetBrains Rider: a cross-platform .NET IDE. Edit, refactor, test and debug ASP.NET, .NET Framework, .NET Core, Xamarin or Unity applications. Learn more and download a 30-day trial!

About Scott

Scott Hanselman is a former professor, former Chief Architect in finance, now speaker, consultant, father, diabetic, and Microsoft employee. He is a failed stand-up comic, a cornrower, and a book author.

facebook twitter subscribe
About   Newsletter
Sponsored By
Hosting By
Dedicated Windows Server Hosting by SherWeb

Announcing .NET Core 2.1 RC 1 Go Live AND .NET Core 3.0 Futures

May 10, '18 Comments [11] Posted in ASP.NET | DotNetCore | WPF
Sponsored By

I just got back from the Microsoft BUILD Conference where Scott Hunter and I announced both .NET Core 2.1 RC1 AND talked about .NET Core 3.0 in the future.

.NET Core 2.1 RC1

First, .NET Core 2.1's Release Candidate is out. This one has a Go Live license and it's very close to release.

You can download and get started with .NET Core 2.1 RC 1, on Windows, macOS, and Linux:

You can see complete details of the release in the .NET Core 2.1 RC 1 release notes. Related instructions, known issues, and workarounds are included in releases notes. Please report any issues you find in the comments or at dotnet/core #1506. ASP.NET Core 2.1 RC 1 and Entity Framework 2.1 RC 1 are also releasing today. You can develop .NET Core 2.1 apps with Visual Studio 2017 15.7, Visual Studio for Mac 7.5, or Visual Studio Code.

Here's a deep dive on the performance benefits which are SIGNIFICANT. It's also worth noting that you can get 2x+ speed improvements for your builds/compiles, by using the .NET Core 2.1 RC SDK for building while continuing to target earlier .NET Core releases, like 2.0 for the Runtime.

  • Go Live - You can put this version in production and get support.
  • Alpine Support - There are docker images at 2.1-sdk-alpine and 2.1-runtime-alpine.
  • ARM Support - We can compile on Raspberry Pi now! .NET Core 2.1 is supported on Raspberry Pi 2+. It isn’t supported on the Pi Zero or other devices that use an ARMv6 chip. .NET Core requires ARMv7 or ARMv8 chips, like the ARM Cortex-A53. There are even Docker images for ARM32
  • Brotli Support - new lossless compression algo for the web.
  • Tons of new Crypto Support.
  • Source Debugging from NuGet Packages (finally!) called "SourceLink."
  • .NET Core Global Tools:
    dotnet tool install -g dotnetsay
    dotnetsay

In fact, if you have Docker installed go try an ASP.NET Sample:

docker pull microsoft/dotnet-samples:aspnetapp
docker run --rm -it -p 8000:80 --name aspnetcore_sample microsoft/dotnet-samples:aspnetapp

.NET Core 3.0

This is huge. You'll soon be able to take your existing WinForms and WPF app (I did this with a 12 year old WPF app!) and swap out the underlying runtime. That means you can run WinForms and WPF on .NET Core 3 on Windows.

"Bringing desktop workloads to run on the top of .NET Core is great. We would love to close the loop and open source them as well. We are investigating how to do that." - Scott Hunter, Director PM, .NET, Microsoft

Why is this cool?

  • WinForms/WPF apps can be self-contained and run in a single folder.

No need to install anything, just xcopy deploy. WinFormsApp1 can't affect WPFApp2 because they can each target their own .NET Core 3 version. Updates to the .NET Framework on Windows are system-wide and can sometimes cause problems with legacy apps. You'll now have total control and update apps one at at time and they can't affect each other. C#, F# and VB already work with .NET Core 2.0. You will be able to build desktop applications with any of those three languages with .NET Core 3.

Secondly, you'll get to use all the new C# 7.x+ (and beyond) features sooner than ever. .NET Core moves fast but you can pick and choose the language features and libraries you want. For example, I can update BabySmash (my .NET 3.5 WPF app) to .NET Core 3.0 and use new C# features AND bring in UWP Controls that didn't exist when BabySmash was first written! WinForms and WPF apps will also get the new lightweight csproj format. More details here and a full video below.

  • Compile to a single EXE

Even more, why not compile the whole app into a single EXE. I can make BabySmash.exe and it'll just work. No install, everything self-contained.

.NET Core 3 will still be cross platform, but WinForms and WPF remain "W is for Windows" - the runtime is swappable, but they still P/Invoke into the Windows APIs. You can look elsewhere for .NET Core cross-platform UI apps with frameworks like Avalonia, Ooui, and Blazor.

Diagram showing that .NET Core will support Windows UI Frameworks

You can check out the video from BUILD here. We show 2.1, 3.0, and some amazing demos like compiling a .NET app into a single exe and running it on a computer from the audience, as well as taking the 12 year old BabySmash WPF app and running it on .NET Core 3.0 PLUS adding a UWP Touch Ink Control!

Lots of cool stuff coming today AND tomorrow with open source .NET Core!


Sponsor: Check out JetBrains Rider: a cross-platform .NET IDE. Edit, refactor, test and debug ASP.NET, .NET Framework, .NET Core, Xamarin or Unity applications. Learn more and download a 30-day trial!

About Scott

Scott Hanselman is a former professor, former Chief Architect in finance, now speaker, consultant, father, diabetic, and Microsoft employee. He is a failed stand-up comic, a cornrower, and a book author.

facebook twitter subscribe
About   Newsletter
Sponsored By
Hosting By
Dedicated Windows Server Hosting by SherWeb

Disclaimer: The opinions expressed herein are my own personal opinions and do not represent my employer's view in any way.
